Polyurethane Foams

Volt

Glow wire resistant polyurethane foam for electrical installations.
EC1plus_(GB)_black_ B2_DIN4102
  • Ideal for fixing junction boxes and cable conduits
  • Can be used up to an environmental temperature of -10 °C
  • Prevents the formation of thermal and acoustic bridges in sealed joints between cable conduits and brickwork
  • Very low VOC emissions: ideal for interior applications

Volt is a one-component polyurethane foam in an aerosol can specially developed for fixing and sealing junction boxes, cable conduits and electrical installations in general. After polymerisation and perfect curing, the foam is resistant to glow wire according to the Glow Wire Test at +850 °C (reference document CEI EN 60695-2-10 (2014-03) – CEI EN 60695-2-11 (2014-08) – test report no.RSP30580 of 22/07/22 Laboratorio Sala Prove BTICINO VARESE).
Screwing the can onto the T2000 (or T500) professional foam gun releases a foaming mass that increases its volume by reacting with atmospheric humidity, loses its initial tackiness, hardens and transforms into a semi-solid, waterproof foam. Adheres permanently to wood, concrete, brick, cement, asbestos, metal, glass and plastic with the exception of polyethylene, Teflon and silicone. Thanks to the dimensional stability and mechanical properties of the cured product, it is ideal for bonding, fixing, insulating, soundproofing, sealing and closing the components of an electrical installation, both on the wall and on the floor. The uniform, predominantly closed cell structure also gives the cured foam heat and sound insulating properties. The cured foam can be cut, drilled, sanded, painted and plastered. Due to the use of a special propellant mixture in the formulation, it can also be used at particularly low ambient temperatures of up to -10 °C. After curing, the product is certified with very low emissions of volatile organic substances (EC1 Plus by GEV) and is perfect for indoor use.

  • Fixing of cable conduits and junction boxes/electrical installations
  • Insulation of corrugated pipes on floor and wall surfaces
  • Sealing of joints between cable ducts and walls
Color Code Application Packaging Packaging size Pallet Barcode

Natural yellow
5633 Gun application can 12x750 ml 42 cardboards 8030334056338
Technical datasheet [pdf]
Download
Glow wire test 850 °C [pdf]
Download
